玻璃钢轴流屋顶风机

您的位置: 首页 产品中心 玻璃钢屋顶轴流风机
产品详情
  • DWT-I型玻璃钢轴流式屋顶通风机

    DWT-I型玻璃钢轴流屋顶通风机广泛适用于中低压、大流量的使用场所。如工矿企业、车间、仓库、体育馆、影剧院、发电厂、化验室、橡胶厂、汽车厂、摩托车厂及纺织、冶金等场所通风换气使用。本系列风机具有造型美观,结构紧凑、强度高、重量轻、耐腐蚀、抗老化、耗电省、噪音低、运转可靠、经济实用、安装维修方便等特点。其所输送气体不允许含有粘性物质、所含粉尘及硬质颗粒≤150mg/m3、气体温度≤60℃、相对湿度≤100%。
  • DWT-I series of axial fiber glass roof fan

    The DWT-I type FRP axial flow roof fan is widely used in medium and low pressure and large flow use places. Such as industrial and mining enterprises, workshops, warehouses, gymnasiums, theaters, power plants, laboratory, rubber factories, automobile factories, motorcycle factories, textile and metallurgy places, etc. This series of fans is characterized by beautiful appearance, compact structure, high strength, light weight, corrosion resistance, anti-aging, low power consumption, low noise, reliable operation, economical and practical, convenient installation and maintenance. The gas is not allowed to contain viscous substances, dust and hard particles is less than or equal to 150mg/m3, the gas temperature are less than 60, the relative humidity is less than 100%.
机 号
Model(No)
功 率
Power(Kw)
转 速
Speed(r/min)
流 量
Volume(M3/h)
全 压
Pressure(Pa)
3 0.37 2900 3300-2600 181-232
0.18 1450 1900-2120 90-110
3.5 0.75 2900 4150-5320 150-230
0.37 1450 3320-2850 100-150
4 1.1 2900 7450-5300 193-250
0.55 1450 5700-4580 176-190
4.5 0.55 1450 6320-5800 125-140
0.37 1450 6067-5520 110-130
5 0.55 1450 8000-5600 135-191
0.37 960 7000-6400 113-131
6 1.5 1450 15000-13000 232-267
1.1 960 11000-9100 168-193
0.55 710 8500-7600 111-136
7 1.1 960 17500-12500 165-212
0.75 710 12000-9200 141-177
8 2.2 960 27000-23000 175-228
1.5 710 20000-16000 129-167
9 4 960 34500-24000 256-202
2.2 710 32000-24000 126-177
10 5.5 960 50000-39000 251-317
3 710 46000-35000 141-183
11.2 7.5 960 41000-53855 215-285

外形及安装尺寸示意图 Lnstallation size diagram

dwt-1玻璃钢轴流式屋顶风机安装尺寸示意图


产品为人工实物测量会有一定误差,相关数据仅作参考,以收到的实物为准。 单位Unit: mm(毫米)

机号
外形尺寸
NO ΦA ΦB C D E F H
3 667 305 300 550 500 485 68
3.5 970 360 340 610 560 520 68
4 970 400 350 620 660 610 68
4.5 1143 460 400 695 700 660 68
5 1143 488 440 740 750 710 68
6 1280 580 510 820 840 825 68
7 1280 710 520 836 900 860 68
8 1410 800 560 950 1000 940 68
9 1760 910 620 1000 1260 1210 68
10 1760 1010 730 1150 1310 1250 68
11.2 1760 1120 730 1200 1450 1350 68
